AOC AG346UCD reviews
Product specifications and review coverage for this exact model.
Image supplied through Icecat
Product overview
AOC AG346UCD is listed in the computer monitors category. The recorded specifications include display diagonal: 86.4 cm (34"); display resolution: 3440 x 1440 pixels; panel type: OLED; maximum refresh rate: 175 Hz. This entry covers manufacturer code AG346UCD. Specifications relate to this exact source record; other editions or packages may differ.
Automatically assembled from the source specifications. This is a factual summary, not a hands-on review.
Expert reviews
No scored critic reviews have been imported for this exact product yet. It remains unrated.
The COR Score gives each publisher one rating. Scores are converted to the same five-point scale.
Specifications
Manufacturer code: AG346UCD. Icecat product 121148469 · Checked 16 Sep 2026. The source lists this code for Great Britain. No specifications are transferred from other editions.
Key specifications
The main features to compare for this exact model. Missing details are not assumed.
| Screen size | 86.4 cm (34") |
|---|---|
| Screen resolution | 3440 x 1440 pixels |
| Panel type | OLED |
| Maximum refresh rate | 175 Hz |
| Response time | 0.03 ms |
| Display brightness (typical) | 1000 cd/m² |
| High Dynamic Range (HDR) supported | Yes |
| HDMI ports | 2 |
| DisplayPort connections | 1 |
More product specifications
Open a section for the details that matter to you.
Audio & listening7 details
| Digital horizontal frequency | 30 - 385 kHz |
|---|---|
| Digital vertical frequency | 48 - 240 Hz |
| Number of speakers | 2 |
| Rated audio power (RMS) | 16 W |
| Built-in speakers | Yes |
| Headphone out | Yes |
| Headphone outputs | 1 |
Display16 details
| Display technology | QD-OLED |
|---|---|
| Touchscreen | No |
| Anti-glare screen | Yes |
| Screen shape | Curved |
| Screen curvature rating | 1800R |
| Contrast ratio (typical) | 150000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.073 billion colours |
| Display diagonal (metric) | 86.36 cm |
| High Dynamic Range (HDR) technology | DisplayHDR 400 True Black |
| Colour gamut standard | Adobe RGB, DCI-P3, sRGB |
| AMD FreeSync refresh rate range | 48 - 175 Hz |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Simplified Chinese, Traditional Chinese, Czech, Dutch, English, Finnish, French, German, Italian, Japanese, Korean, Croatian, Polish, Portuguese, Russian, Spanish, Swedish, Turkish, Ukrainian |
| Native refresh rate | 60 Hz |
Processor, memory & storage1 detail
| Frameless design | Yes |
|---|
Camera, image & video1 detail
| Built-in camera | No |
|---|
Connections & wireless12 details
| Built-in USB hub | Yes |
|---|---|
| USB hub version | 3.2 Gen 1 (3.1 Gen 1) |
| USB upstream port type | USB Type-B |
| Number of upstream ports | 1 |
| USB Type-A downstream ports quantity | 3 |
| HDMI | Yes |
| HDMI version | 2.0 |
| DisplayPort version | 1.4 |
| Headphone connectivity | 3.5 mm |
| Panel mounting interface | 100 x 100 mm |
| DisplayPort cable length | 1.8 m |
| HDMI cable length | 1.8 m |
Power & battery12 details
| Energy efficiency class (SDR) | F |
|---|---|
| Energy efficiency class (HDR) | F |
| Energy consumption (SDR) per 1000 hours | 31 kWh |
| Energy consumption (HDR) per 1000 hours | 31 kWh |
| Power consumption (typical) | 100 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 2.5 A |
| Power supply type | Internal |
| Energy efficiency scale | A to G |
Controls & features1 detail
| Shadow control | Yes |
|---|
Design & dimensions13 details
| Product colour | Black, Grey |
|---|---|
| Front bezel colour | Black |
| VESA mounting | Yes |
| Height adjustment | Yes |
| Adjustable height (max) | 13 cm |
| Width (with stand) | 811.7 mm |
| Depth (with stand) | 294.3 mm |
| Height (with stand) | 551.2 mm |
| Weight (with stand) | 10.8 kg |
| Width (without stand) | 811.7 mm |
| Depth (without stand) | 130.2 mm |
| Height (without stand) | 361.2 mm |
| Weight (without stand) | 7.65 kg |
Software & compatibility3 details
| Brand specific technologies | Crosshair |
|---|---|
| Compliance certificates | CB, CE, Federal Communications Commission (FCC), KC, KCC, RoHS |
| Certification | WEEE,REACH compliant,RoHs compliant |
Further product details39 details
| HD type | Wide Quad HD |
|---|---|
| Native aspect ratio | 21:9 |
| LED backlight | Yes |
| Backlight type | W-LED |
| Response time measurement type | GTG (Gray to Gray) |
| Pixel pitch | 0.2315 x 0.2315 mm |
| Pixel density | 109.68 ppi |
| Viewable size, horizontal | 80.1 cm |
| Viewable size, vertical | 33.7 cm |
| Haze rate | 35% |
| Surface hardness | 3H |
| sRGB coverage (typical) | 139.1% |
| Adobe RGB coverage | 97.8% |
| DCI-P3 coverage | 99.3% |
| NVIDIA G-SYNC | Yes |
| AMD FreeSync | Yes |
| AMD FreeSync type | FreeSync Premium |
| VESA Adaptive Sync support | Yes |
| Flicker-free technology | Yes |
| Low Blue Light technology | Yes |
| Game mode | Yes |
| Market positioning | Gaming |
| Detachable stand | Yes |
| HDCP | Yes |
| HDCP version | 2.2 |
| Cable management | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Swivelling | Yes |
| Swivel angle range | 28 - 28° |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 23° |
| Picture-in-Picture | Yes |
| Doesn't contain | Mercury, PVC/BFR |
| Low input lag | Yes |
| FPS counter | Yes |
| Dial point | Yes |
| Picture-by-Picture (PbP) | Yes |
| Bezel thickness type | Frameless |
Packaging & supplied accessories6 details
| Package width | 930 mm |
|---|---|
| Package depth | 226 mm |
| Package height | 470 mm |
| Package weight | 14.2 kg |
| Cables included | AC, HDMI, DisplayPort, USB |
| Warranty period | 3 year(s) |
Specifications describe the supplied product data, not measured review results. Battery life, range and performance figures are source claims and can vary with use.
