Product overview
ASUS 90LM06R1-B01170 is listed in the computer monitors category. The recorded specifications include display diagonal: 81.3 cm (32"); display resolution: 2560 x 1440 pixels; panel type: IPS; maximum refresh rate: 165 Hz. This entry covers manufacturer code 90LM06R1-B01170. Specifications relate to this exact source record; other editions or packages may differ.
Automatically assembled from the source specifications. This is a factual summary, not a hands-on review.
Expert reviews
No scored critic reviews have been imported for this exact product yet. It remains unrated.
The COR Score gives each publisher one rating. Scores are converted to the same five-point scale.
Specifications
Manufacturer code: 90LM06R1-B01170. Icecat product 93735607 · Checked 20 Sep 2026. The source lists this code for Great Britain. No specifications are transferred from other editions.
Key specifications
The main features to compare for this exact model. Missing details are not assumed.
| Screen size | 81.3 cm (32") |
|---|---|
| Screen resolution | 2560 x 1440 pixels |
| Panel type | IPS |
| Maximum refresh rate | 165 Hz |
| Response time | 5 ms |
| Display brightness (typical) | 450 cd/m² |
| HDMI ports | 2 |
| DisplayPort connections | 1 |
More product specifications
Open a section for the details that matter to you.
Audio & listening7 details
| Digital horizontal frequency | 30 - 250 kHz |
|---|---|
| Digital vertical frequency | 48 - 165 Hz |
| Number of speakers | 2 |
| Rated audio power (RMS) | 4 W |
| Built-in speakers | Yes |
| Headphone out | Yes |
| Headphone outputs | 1 |
Display11 details
| Touchscreen | No |
|---|---|
| Display surface | Matt |
| Screen shape | Flat |
| Contrast ratio (typical) | 1000:1 |
| Contrast ratio (dynamic) | 100000000:1 |
| Dynamic contrast ratio marketing name | SmartContrast |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.073 billion colours |
| Colour gamut standard | DCI-P3 |
| Colour gamut | 95% |
Camera, image & video1 detail
| Built-in camera | No |
|---|
Connections & wireless10 details
| Built-in USB hub | Yes |
|---|---|
| USB hub version | 3.2 Gen 1 (3.1 Gen 1) |
| Number of upstream ports | 1 |
| Number of USB Type-C upstream ports quantity | 1 |
| USB Type-A downstream ports quantity | 4 |
| HDMI | Yes |
| HDMI version | 2.0 |
| DisplayPort version | 1.4 |
| Headphone connectivity | 3.5 mm |
| Panel mounting interface | 100 x 100 mm |
Power & battery11 details
| USB Power Delivery up to | 90 W |
|---|---|
| Energy efficiency class (SDR) | G |
| Energy efficiency class (HDR) | G |
| Energy consumption (SDR) per 1000 hours | 40 kWh |
| Energy consumption (HDR) per 1000 hours | 80 kWh |
| Power consumption (typical) | 28 W |
| Power consumption (off) | 0.5 W |
| Power consumption (PowerSave) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Energy efficiency scale | A to G |
Design & dimensions12 details
| Product colour | Black |
|---|---|
| VESA mounting | Yes |
| Height adjustment | Yes |
| Adjustable height (max) | 13 cm |
| Width (with stand) | 727.1 mm |
| Depth (with stand) | 245 mm |
| Height (with stand) | 601.5 mm |
| Weight (with stand) | 11.7 kg |
| Width (without stand) | 727.1 mm |
| Depth (without stand) | 67.7 mm |
| Height (without stand) | 428.1 mm |
| Weight (without stand) | 7.15 kg |
Software & compatibility1 detail
| Certification | TÜV Flicker-free TÜV Low Blue Light VESA DisplayHDR 600 AMD FreeSync Premium Pro Calman Verified |
|---|
Further product details19 details
| HD type | Wide Quad HD |
|---|---|
| Native aspect ratio | 16:9 |
| Backlight type | LED |
| Pixel pitch | 0.277 x 0.277 mm |
| Viewable size, horizontal | 70.8 cm |
| Viewable size, vertical | 39.9 cm |
| sRGB coverage (typical) | 100% |
| NVIDIA G-SYNC | No |
| Flicker-free technology | Yes |
| Low Blue Light technology | Yes |
| Market positioning | Graphics design |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Pivot | Yes |
| Pivot angle | 90 - -90° |
| Swivelling | Yes |
| Swivel angle range | 30 - -30° |
| Tilt adjustment | Yes |
| Tilt angle range | 23 - -5° |
Packaging & supplied accessories5 details
| Package width | 840 mm |
|---|---|
| Package depth | 280 mm |
| Package height | 516 mm |
| Package weight | 16.8 kg |
| Harmonized System (HS) code | 85285210 |
Specifications describe the supplied product data, not measured review results. Battery life, range and performance figures are source claims and can vary with use.
