ASUS PB60-B7137MD reviews
Product specifications and review coverage for this exact model.
Image supplied through Icecat
Product overview
ASUS 90MS01E1-M01380 is listed in the pcs/workstations category. The recorded specifications include processor family: Intel® Core™ i7; internal memory: 8 GB; total storage capacity: 256 GB; operating system installed: Windows 10 Pro. This entry covers manufacturer code 90MS01E1-M01380. Specifications relate to this exact source record; other editions or packages may differ.
Automatically assembled from the source specifications. This is a factual summary, not a hands-on review.
Expert reviews
No scored critic reviews have been imported for this exact product yet. It remains unrated.
The COR Score gives each publisher one rating. Scores are converted to the same five-point scale.
Specifications
Manufacturer code: 90MS01E1-M01380. Icecat product 62360340 · Checked 19 Sep 2026. The source lists this code for Great Britain. No specifications are transferred from other editions.
Key specifications
The main features to compare for this exact model. Missing details are not assumed.
| Processor family | Intel® Core™ i7 |
|---|---|
| Processor model | i7-8700T |
| Memory (RAM) | 8 GB |
| Total storage capacity | 256 GB |
| Storage media | SSD |
| Operating system installed | Windows 10 Pro |
| Discrete graphics card model | Not available |
| Chassis type | Mini Tower |
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
More product specifications
Open a section for the details that matter to you.
Audio & listening3 details
| Configurable TDP-down frequency | 1.9 GHz |
|---|---|
| Headphone outputs | 1 |
| Microphone in | Yes |
Display3 details
| Number of displays supported (on-board graphics) | 3 |
|---|---|
| Display included | No |
| Number of displays supported | 2 |
Processor, memory & storage44 details
| Processor manufacturer | Intel |
|---|---|
| Processor generation | 8th gen Intel® Core™ i7 |
| Processor cores | 6 |
| Processor threads | 12 |
| Processor boost frequency | 4 GHz |
| Processor frequency | 2.4 GHz |
| Processor cache | 12 MB |
| Processor cache type | Smart Cache |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor codename | Coffee Lake |
| Number of processors installed | 1 |
| Processor socket | LGA 1151 (Socket H4) |
| Maximum internal memory supported by processor | 64 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2666 MHz |
| Memory bandwidth supported by processor (max) | 41.6 GB/s |
| ECC supported by processor | No |
| Maximum internal memory | 32 GB |
| Internal memory type | DDR4-SDRAM |
| Memory layout (slots x size) | 1 x 8 GB |
| Memory slots | 2x SO-DIMM |
| Memory clock speed | 2400 MHz |
| Number of storage drives supported | 2 |
| SSD capacity | 256 GB |
| SSD form factor | M.2 |
| Card reader integrated | No |
| Discrete graphics card | No |
| On-board graphics card | Yes |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card model | Intel® UHD Graphics 630 |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card dynamic frequency (max) | 1200 MHz |
| Maximum on-board graphics card memory | 64 GB |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card ID | 0x3E92 |
| Motherboard chipset | Intel® B360 |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Processor package size | 37.5 x 37.5 mm |
| Processor code | SR3WX |
| Intel Stable Image Platform Program (SIPP) version | 1.00 |
| Processor ARK ID | 129948 |
| Conflict-Free processor | Yes |
Camera, image & video4 details
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
|---|---|
| Intel Clear Video Technology | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Intel® Quick Sync Video Technology | Yes |
Connections & wireless19 details
| Graphics card HDMI ports quantity | 1 |
|---|---|
| Graphics card DisplayPorts quantity | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| Number of antenna connectors | 1 |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| DisplayPort connections | 1 |
| HDMI ports | 1 |
| HDMI version | 1.4 |
| Ethernet LAN (RJ-45) ports | 1 |
| DVI port | No |
| DC-in jack | Yes |
| Serial ports quantity | 1 |
Power & battery2 details
| Power supply | 65 W |
|---|---|
| AC adapter included | Yes |
Controls & features1 detail
| On/off button | Yes |
|---|
Design & dimensions13 details
| Thermal Design Power (TDP) | 35 W |
|---|---|
| Product type | Mini PC |
| Placement supported | Horizontal/Vertical |
| VESA mounting | Yes |
| Product colour | Black |
| Intel Identity Protection Technology version | 1.00 |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Width | 175 mm |
| Depth | 175 mm |
| Height | 34.2 mm |
| Weight | 1.19 kg |
| VESA mount included | Yes |
| Mounting feet | Yes |
Software & compatibility4 details
| Operating system architecture | 64-bit |
|---|---|
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
| Certification | BSMI/CB/CE/FCC/UL/CCC/Energy Star/C-Tick/WiFi/RF/VCCI |
Further product details42 details
| System bus rate | 8 GT/s |
|---|---|
| Bus type | DMI3 |
| Configurable TDP-down | 25 W |
| Tjunction | 100 °C |
| PCI Express slots version | 3.0 |
| Maximum number of PCI Express lanes | 16 |
| PCI Express configurations | 1x16, 1x8+2x4, 2x8 |
| Stepping | U0 |
| Memory channels | Dual-channel |
| Optical drive type | No |
| Number of SSDs installed | 1 |
| Market positioning | Business |
| Cabling technology | 10/100/1000Base-T(X) |
| Number of 2.5" bays | 1 |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Drivers included | Yes |
| Intel 64 | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Embedded options available | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel TSX-NI | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Secure Key | Yes |
| Intel® OS Guard | Yes |
| Intel Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| Intel Enhanced Halt State | Yes |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Thermal solution specification | PCG 2015A |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Secure Key Technology version | 1.00 |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel TSX-NI version | 1.00 |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Stand included | Yes |
| Sustainability certificates | ENERGY STAR |
Packaging & supplied accessories1 detail
| Manual | Yes |
|---|
Specifications describe the supplied product data, not measured review results. Battery life, range and performance figures are source claims and can vary with use.
