Product overview
ASUS 90PT01H1-M04730 is listed in the all-in-one pcs/workstations category. The recorded specifications include processor family: Intel® Celeron®; internal memory: 4 GB; total storage capacity: 128 GB. This entry covers manufacturer code 90PT01H1-M04730. Specifications relate to this exact source record; other editions or packages may differ.
Automatically assembled from the source specifications. This is a factual summary, not a hands-on review.
Expert reviews
No scored critic reviews have been imported for this exact product yet. It remains unrated.
The COR Score gives each publisher one rating. Scores are converted to the same five-point scale.
Specifications
Manufacturer code: 90PT01H1-M04730. Icecat product 35361040 · Checked 20 Sep 2026. The source lists this code for Great Britain. No specifications are transferred from other editions.
Key specifications
The main features to compare for this exact model. Missing details are not assumed.
| Processor family | Intel® Celeron® |
|---|---|
| Processor model | N3150 |
| Memory (RAM) | 4 GB |
| Total storage capacity | 128 GB |
| Storage media | SSD |
| Discrete graphics card model | Not available |
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
More product specifications
Open a section for the details that matter to you.
Audio & listening6 details
| Built-in speakers | Yes |
|---|---|
| Rated audio power (RMS) | 3 W |
| Built-in microphone | Yes |
| Headphone outputs | 1 |
| Microphone in | Yes |
| Intel® High Definition Audio (Intel® HD Audio) | Yes |
Display5 details
| Screen size | 39.6 cm (15.6") |
|---|---|
| Screen resolution | 1366 x 768 pixels |
| Touchscreen | Yes |
| Screen shape | Flat |
| Number of displays supported (on-board graphics) | 3 |
Processor, memory & storage39 details
| Processor manufacturer | Intel |
|---|---|
| Processor cores | 4 |
| Processor threads | 4 |
| Processor boost frequency | 2.08 GHz |
| Processor frequency | 1.6 GHz |
| Processor cache | 2 MB |
| Processor cache type | Smart Cache |
| Processor socket | BGA 1170 |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor codename | Braswell |
| Processor series | Intel Celeron N3000 series |
| Processor code | SR29F |
| Maximum internal memory supported by processor | 8 GB |
| Conflict-Free processor | Yes |
| Memory types supported by processor | DDR3L-SDRAM |
| Memory clock speeds supported by processor | 1600 MHz |
| Memory channels supported by processor | Dual |
| ECC supported by processor | No |
| Internal memory type | DDR3L-SDRAM |
| Maximum internal memory | 4 GB |
| Memory slots | 1 |
| Memory slots type | SO-DIMM |
| Memory clock speed | 1600 MHz |
| SSD capacity | 128 GB |
| Card reader integrated | Yes |
| Compatible memory cards | MMC, SD |
| Discrete graphics card | No |
| On-board graphics card | Yes |
| On-board graphics card family | Intel® HD Graphics |
| On-board graphics card model | Intel® HD Graphics |
| On-board graphics card base frequency | 320 MHz |
| On-board graphics card burst frequency | 640 MHz |
| Maximum on-board graphics card memory | 8 GB |
| Intel Stable Image Platform Program (SIPP) | No |
| Processor package size | 25 x 27 mm |
| Intel Stable Image Platform Program (SIPP) version | 0.00 |
| Intel Rapid Storage Technology | No |
| Processor ARK ID | 87258 |
Camera, image & video5 details
| Built-in camera | Yes |
|---|---|
| Intel® Quick Sync Video Technology | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel Clear Video Technology | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
Connections & wireless13 details
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
|---|---|
| Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 4.0 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| HDMI ports | 1 |
| VGA (D-Sub) ports quantity | 1 |
| DC-in jack | Yes |
| Serial ports quantity | 2 |
| Intel® Wireless Display (Intel® WiDi) | Yes |
Power & battery1 detail
| AC adapter power | 45 W |
|---|
Controls & features4 details
| Intel® Smart Response Technology | No |
|---|---|
| Intel Smart Connect Technology | No |
| Intel Smart Connect Technology version | 0.00 |
| Intel Smart Response Technology version | 0.00 |
Design & dimensions10 details
| Thermal Design Power (TDP) | 6 W |
|---|---|
| Scenario Design Power (SDP) | 4 W |
| Product colour | Black |
| Product type | All-in-One PC |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Width (with stand) | 377.5 mm |
| Depth (with stand) | 28.5 mm |
| Height (with stand) | 247 mm |
| Weight (with stand) | 2.19 kg |
Further product details42 details
| HD type | HD |
|---|---|
| LED backlight | Yes |
| Touch technology | Multi-touch |
| Native aspect ratio | 16:9 |
| System bus rate | 5 GT/s |
| PCI Express slots version | 2.0 |
| Stepping | C0 |
| Maximum number of PCI Express lanes | 4 |
| PCI Express configurations | 1x4, 4x1 |
| Tjunction | 90 °C |
| Integrated 4G WiMAX | No |
| Number of SSDs installed | 1 |
| Optical drive type | No |
| Number of execution units | 12 |
| Intel® Turbo Boost Technology | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Intel® Small Business Advantage (Intel® SBA) | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Insider™ | No |
| Intel® InTru™ 3D Technology | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | No |
| Intel Enhanced Halt State | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Secure Key | Yes |
| Intel® OS Guard | No |
| Intel 64 | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| UART | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | No |
| Intel Secure Boot | Yes |
| Intel Secure Boot Technology version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Small Business Advantage (SBA) version | 0.00 |
| Mouse included | No |
| Keyboard included | No |
Specifications describe the supplied product data, not measured review results. Battery life, range and performance figures are source claims and can vary with use.
