DELL Pro JX4DR-3YPS
tbdCOR ScoreAvailable after 3 critic reviews
Desktop PCs
DELL JX4DR-3YPS reviews
Product specifications and review coverage for this exact model.
Image supplied through Icecat
Product overview
DELL JX4DR-3YPS is listed in the pcs/workstations category. The recorded specifications include processor family: Intel® Core™ i5; internal memory: 16 GB; total storage capacity: 512 GB; operating system installed: Windows 11 Pro. This entry covers manufacturer code JX4DR-3YPS. Specifications relate to this exact source record; other editions or packages may differ.
Automatically assembled from the source specifications. This is a factual summary, not a hands-on review.
Expert reviews
No scored critic reviews have been imported for this exact product yet. It remains unrated.
The COR Score gives each publisher one rating. Scores are converted to the same five-point scale.
Specifications
Manufacturer code: JX4DR-3YPS. Icecat product 149911066 · Checked 22 Sep 2026. The source lists this code for Great Britain. No specifications are transferred from other editions.
Key specifications
The main features to compare for this exact model. Missing details are not assumed.
| Processor family | Intel® Core™ i5 |
|---|---|
| Processor model | i5-14500 |
| Memory (RAM) | 16 GB |
| Total storage capacity | 512 GB |
| Storage media | SSD |
| Operating system installed | Windows 11 Pro |
| Discrete graphics card model | Not available |
| Chassis type | Slim PC |
| Wi-Fi | No |
| Ethernet LAN | Yes |
More product specifications
Open a section for the details that matter to you.
Audio & listening6 details
| Performance-core Max Turbo Frequency | 5 GHz |
|---|---|
| Efficient-core Max Turbo Frequency | 3.7 GHz |
| Performance-core base frequency | 2.6 GHz |
| Efficient-core base frequency | 1.9 GHz |
| Audio chip | Realtek ALC3204 |
| Audio system | High Definition Audio |
Display1 detail
| Display included | No |
|---|
Processor, memory & storage22 details
| Processor manufacturer | Intel |
|---|---|
| Processor generation | Intel® Core™ i5 (14th gen) |
| Processor cores | 14 |
| Processor threads | 20 |
| Processor boost frequency | 5 GHz |
| Processor cache | 24 MB |
| Processor cache type | Smart Cache |
| Number of processors installed | 1 |
| Processor base power | 65 W |
| Maximum internal memory | 64 GB |
| Internal memory type | DDR5-SDRAM |
| Memory layout (slots x size) | 1 x 16 GB |
| Memory slots | 2x DIMM |
| Number of storage drives installed | 1 |
| SSD capacity | 512 GB |
| SSD form factor | M.2 |
| Discrete graphics card | No |
| On-board graphics card | Yes |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card model | Intel UHD Graphics 770 |
| Storage temperature (T-T) | -40 - 65 °C |
| Storage relative humidity (H-H) | 0 - 95% |
Printing, scanning & paper1 detail
| Total carbon footprint (kg of CO2e) | 163 |
|---|
Connections & wireless16 details
| SSD interface | PCI Express |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| LAN controller | Intel® I219-LM |
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| DisplayPort connections | 1 |
| DisplayPort version | 1.4a |
| HDMI ports | 1 |
| HDMI version | 2.1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
| DC-in jack | Yes |
| Number of rear USB ports | 4 |
| Number of front USB ports | 4 |
| Number of SATA III connectors | 2 |
Power & battery4 details
| Power supply | 180 W |
|---|---|
| Power supply input voltage | 90 - 264 V |
| Power supply input frequency | 47/63 Hz |
| Carbon emissions, energy usage (kg of CO2e) | 58.52 |
Controls & features1 detail
| Operating temperature (T-T) | 10 - 35 °C |
|---|
Design & dimensions7 details
| Product type | PC |
|---|---|
| Placement supported | Horizontal/Vertical |
| Product colour | Black |
| Width | 95 mm |
| Depth | 293 mm |
| Height | 303.5 mm |
| Weight | 5.89 kg |
Software & compatibility2 details
| Operating system architecture | 64-bit |
|---|---|
| Trial software | Activate Your Microsoft 365 For A 30 Day Trial |
Further product details33 details
| Performance cores | 6 |
|---|---|
| Efficient cores | 8 |
| Maximum turbo power | 154 W |
| Non-ECC | Yes |
| Memory channels | Single-channel |
| Memory data transfer rate | 4800 MT/s |
| Optical drive type | No |
| Total SSDs capacity | 512 GB |
| Number of SSDs installed | 1 |
| NVMe | Yes |
| On-board GPU manufacturer | Intel |
| Market positioning | Business |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Cabling technology | 10/100/1000Base-T(X) |
| PCI Express x1 (Gen 3.x) slots | 2 |
| PCI Express x16 (Gen 3.x) slots | 1 |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Intel® vPro™ Platform Eligibility | Yes |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating altitude | -15.2 - 3048 m |
| Non-operating altitude | -15.2 - 10668 m |
| Operating vibration | 0.66 G |
| Non-operating vibration | 1.3 G |
| Operating shock | 110 G |
| Non-operating shock | 160 G |
| Sustainability certificates | ENERGY STAR, EPEAT Climate +, EPEAT Gold |
| Doesn't contain | PVC/BFR |
| Carbon emissions, manufacturing (kg of CO2e) | 91.12 |
| Carbon emissions, logistics (kg of CO2e) | 9.94 |
| Carbon emissions, end-of-life (kg of CO2e) | 3.42 |
| PAIA version | GaBi version 1, 2024 |
Packaging & supplied accessories1 detail
| Cables included | AC |
|---|
Specifications describe the supplied product data, not measured review results. Battery life, range and performance figures are source claims and can vary with use.
