Product specifications and review coverage for this exact model.
COR ScoretbdAvailable after 3 critic reviews0 critics
Image supplied through Icecat
Product overview
HP BR5A5EA is listed in the laptops category. The recorded specifications include display diagonal: 40.6 cm (16"); processor family: Intel Core Ultra 9; internal memory: 32 GB; total storage capacity: 2 TB. This entry covers manufacturer code BR5A5EA. Specifications relate to this exact source record; other editions or packages may differ.
Automatically assembled from the source specifications. This is a factual summary, not a hands-on review.
Expert reviews
No scored critic reviews have been imported for this exact product yet. It remains unrated.
The COR Score gives each publisher one rating. Scores are converted to the same five-point scale.
Specifications
Manufacturer code: BR5A5EA. Icecat product 130872660 · Checked 16 Sep 2026. The source lists this code for Great Britain. No specifications are transferred from other editions.
Key specifications
The main features to compare for this exact model. Missing details are not assumed.
HP OMEN MAX Gaming 16-ah0508na — key specifications
Screen size
40.6 cm (16")
Screen resolution
2560 x 1600 pixels
Processor family
Intel Core Ultra 9
Processor model
275HX
Memory (RAM)
32 GB
Total storage capacity
2 TB
Storage media
SSD
Operating system installed
Windows 11 Home
Discrete graphics card model
NVIDIA GeForce RTX 5090
Weight
2.68 kg
More product specifications
Open a section for the details that matter to you.
Audio & listening15 details
HP OMEN MAX Gaming 16-ah0508na — Audio & listening
Introduction year
2025
Performance-core Max Turbo Frequency
5.4 GHz
Efficient-core Max Turbo Frequency
4.6 GHz
Performance-core base frequency
2.7 GHz
Efficient-core base frequency
2.1 GHz
Discrete GPU manufacturer
NVIDIA
Audio system
DTS:X Ultra
Built-in speakers
Yes
Number of built-in speakers
2
Built-in microphone
Yes
Number of microphones
2
Microphone in
Yes
HP Audio Boost
Yes
HP speaker type
HP Dual Speakers
Height (rear)
2.48 cm
Display12 details
HP OMEN MAX Gaming 16-ah0508na — Display
Touchscreen
No
Panel type
OLED
Display number of colours
1.07 billion colours
Display glass type
Edge to Edge Glass
Display bezel technology
Micro-Edge
Display brightness
400 cd/m²
Display diagonal (metric)
40.6 cm
Colour gamut
100%
Display response rise/fall
0.2 ms
Maximum refresh rate
240 Hz
High Dynamic Range (HDR) supported
Yes
High Dynamic Range (HDR) technology
High Dynamic Range (HDR) 500, High Dynamic Range (HDR) 1500
Processor, memory & storage25 details
HP OMEN MAX Gaming 16-ah0508na — Processor, memory & storage
Processor manufacturer
Intel
Processor generation
Intel Core Ultra (Series 2)
Processor cores
24
Processor threads
24
Processor boost frequency
5.4 GHz
Processor cache
36 MB
Processor cache type
L3
Processor base power
55 W
Neural processor unit (NPU)
Intel AI Boost
AI software frameworks supported by NPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to
36 TOPs
Internal memory type
DDR5-SDRAM
Memory clock speed
5600 MHz
Memory layout (slots x size)
2 x 16 GB
Memory slots (available)
2
Maximum internal memory
32 GB
SSD capacity
2 TB
SSD form factor
M.2
Discrete graphics card memory
24 GB
Discrete graphics memory type
GDDR7
On-board graphics card
Yes
Discrete graphics card
Yes
On-board graphics card family
Intel® Graphics
On-board graphics card model
Intel® Graphics
Motherboard chipset
Intel HM870
Camera, image & video7 details
HP OMEN MAX Gaming 16-ah0508na — Camera, image & video
Front camera
Yes
Front camera resolution
1920 x 1080 pixels
Front camera HD type
Full HD
Infrared (IR) camera
Yes
Privacy camera
Yes
HP Imagepad
Yes
HP front camera
HP TrueVision FHD IR
Printing, scanning & paper1 detail
HP OMEN MAX Gaming 16-ah0508na — Printing, scanning & paper
Total carbon footprint (kg of CO2e)
470.504
Connections & wireless19 details
HP OMEN MAX Gaming 16-ah0508na — Connections & wireless
SSD interface
PCI Express 4.0
Wi-Fi
Yes
Top Wi-Fi standard
Wi-Fi 7 (802.11be)
Wi-Fi standards
Wi-Fi 7 (802.11be)
Mobile network connection
No
Ethernet LAN
Yes
Ethernet LAN data rates
2500,10,100,1000 Mbit/s
Bluetooth
Yes
Bluetooth version
5.4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
USB4 Gen 3x2 ports quantity
2
Ethernet LAN (RJ-45) ports
1
HDMI ports
1
HDMI version
2.1
Thunderbolt 4 ports quantity
2
Combo headphone/mic port
Yes
USB Type-C DisplayPort Alternate Mode
Yes
USB Sleep-and-Charge
Yes
USB Sleep-and-Charge ports
2
Power & battery12 details
HP OMEN MAX Gaming 16-ah0508na — Power & battery
Battery technology
Lithium Polymer (LiPo)
Number of battery cells
6
Battery capacity
83 Wh
Fast charging
Yes
Fast charging time (50%)
30 min
AC adapter power
330 W
AC adapter frequency
50 - 60 Hz
AC adapter input voltage
100 - 240 V
USB Type-C charging port
Yes
USB Power Delivery (USB PD)
Yes
AC adapter included
Yes
Supplied AC adapter type
Sandblasted cover and base, paint finish keyboard frame
Controls & features3 details
HP OMEN MAX Gaming 16-ah0508na — Controls & features
WLAN controller model
Intel Wi-Fi 7 BE200
WLAN controller manufacturer
Intel
Temperature sensor
Yes
Design & dimensions14 details
HP OMEN MAX Gaming 16-ah0508na — Design & dimensions
Colour name
Shadow black
Product type
Laptop
Product colour
Black
Form factor
Clamshell
RGB colour space
DCI-P3
Memory form factor
SO-DIMM
Keyboard backlit colour
RGB
Keyboard colour name
Shadow black
Password protection
Yes
Password protection type
BIOS, Power on
Sustainable technologies and materials
Ocean-bound plastic in bezel; Keyboard keycaps and scissors contain post-consumer recycled plastic; Recycled metal in cover, base and hinge cap(s)
Width
356.5 mm
Depth
269 mm
Height (front)
2.29 cm
Software & compatibility4 details
HP OMEN MAX Gaming 16-ah0508na — Software & compatibility
Original brand name
HP
Pre-installed software
Otter.ai, 1 month trial for new Microsoft 365 customers, McAfee Online Protection 30-day trial; 1-month Adobe free trial offer; PC Game Pass 3-month trial
Trial software
100 GB Dropbox storage for 3 months
HP Software provided
HP Support Assistant; HP Connection Optimizer; OMEN Gaming Hub
Further product details42 details
HP OMEN MAX Gaming 16-ah0508na — Further product details
Market positioning
Gaming
HD type
WQXGA
LED backlight
Yes
Native aspect ratio
16:10
DCI-P3 coverage
100%
Performance cores
8
Efficient cores
16
Maximum turbo power
160 W
Sparsity support
Yes
Windows Studio effects support
Yes
NPU performance up to
13 TOPs
GPU performance up to
8 TOPs
Total SSDs capacity
2 TB
Number of SSDs installed
1
NVMe
Yes
Optical drive type
No
On-board GPU manufacturer
Intel
NVIDIA G-SYNC
Yes
Privacy type
Privacy shutter
Antenna type
2x2
Intel® Thunderbolt 4
Yes
Pointing device
Touchpad
Numeric keypad
Yes
Keyboard backlit
Yes
Keyboard backlit zone
Per-key RGB
Full-size keyboard
Yes
Intel® Turbo Boost Technology
Yes
HP Security tools
Camera privacy shutter; Trusted Platform Module (Firmware TPM) support
HP Artificial Intelligence
AI PC
HP segment
Home
HP GTIN (EAN/UPC)
199251505744
Trusted Platform Module (TPM)
Yes
Sustainability certificates
EPEAT Gold
Carbon emissions, manufacturing (kg of CO2e)
422.093
Carbon emissions, logistics (kg of CO2e)
8.776
Carbon emissions, end-of-life (kg of CO2e)
1.196
Total carbon emissions, w/o use phase (kg of CO2e)
1 year (1/1/0) limited warranty includes 1 year of parts and labor. No on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply.
Packaging & supplied accessories5 details
HP OMEN MAX Gaming 16-ah0508na — Packaging & supplied accessories
Country of origin
China
Package width
94 mm
Package depth
428 mm
Package height
332 mm
Package weight
4.74 kg
Specifications describe the supplied product data, not measured review results. Battery life, range and performance figures are source claims and can vary with use.
