iiyama TF1534MC-B7X reviews
Product specifications and review coverage for this exact model.
Image supplied through Icecat
Product overview
iiyama TF1534MC-B7X is listed in the computer monitors category. The recorded specifications include display diagonal: 38.1 cm (15"); display resolution: 1024 x 768 pixels; panel type: TN. This entry covers manufacturer code TF1534MC-B7X. Specifications relate to this exact source record; other editions or packages may differ.
Automatically assembled from the source specifications. This is a factual summary, not a hands-on review.
Expert reviews
No scored critic reviews have been imported for this exact product yet. It remains unrated.
The COR Score gives each publisher one rating. Scores are converted to the same five-point scale.
Specifications
Manufacturer code: TF1534MC-B7X. Icecat product 89585628 · Checked 15 Sep 2026. The source lists this code for Great Britain. No specifications are transferred from other editions.
Key specifications
The main features to compare for this exact model. Missing details are not assumed.
| Screen size | 38.1 cm (15") |
|---|---|
| Screen resolution | 1024 x 768 pixels |
| Panel type | TN |
| Response time | 8 ms |
| Display brightness (typical) | 370 cd/m² |
| HDMI ports | 1 |
| DisplayPort connections | 1 |
More product specifications
Open a section for the details that matter to you.
Display17 details
| Display technology | LED |
|---|---|
| Touchscreen | Yes |
| Touchscreen type | Multi-user |
| Touchscreen technology | Projected capacitive system |
| Display brightness | 330 cd/m² |
| Screen shape | Flat |
| Contrast ratio (typical) | 700:1 |
| Viewing angle, horizontal | 170° |
| Viewing angle, vertical | 160° |
| Display number of colours | 16.2 million colours |
| Display diagonal (metric) | 38 cm |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Traditional Chinese, German, English, Spanish, French, Italian, Japanese |
| Display viewable area (HxV) | 304 x 228 mm |
| Brightness | 330 cd/m² |
| Active display area (W x H) | 304 x 228 mm |
| Native refresh rate | 60 Hz |
Printing, scanning & paper1 detail
| Horizontal scan range | 31.4 - 60 kHz |
|---|
Connections & wireless8 details
| Number of simultaneous touchpoints | 10 |
|---|---|
| USB Touch port | Yes |
| VGA (D-Sub) ports quantity | 1 |
| HDMI | Yes |
| Panel mounting interface | 100 x 100 mm |
| USB cable length | 1.8 m |
| DisplayPort cable length | 1.8 m |
| HDMI cable length | 1.8 m |
Power & battery10 details
| Energy efficiency class (SDR) | E |
|---|---|
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 10 kWh |
| Power consumption (typical) | 9 W |
| Power consumption (standby) | 0.7 W |
| Power consumption (off) | 0.3 W |
| AC adapter output voltage | 12 V |
| Power supply type | External |
| Energy efficiency scale | A to G |
| AC adapter included | Yes |
Controls & features2 details
| User controls | picture (contrast, brightness, H.position, V.position, phase, clock, auto adjust), advanced (color temp., sharpness), OSD (time out, position, H-position, V-position, Touch switch), option (reset, language, source select, display mode, factory) |
|---|---|
| Control panel | Menu, Scroll up/ Brightness, Scroll down/ Contrast, Select, Power |
Design & dimensions18 details
| Product colour | Black |
|---|---|
| Front bezel colour | Black |
| VESA mounting | Yes |
| Wall mountable | Yes |
| Width (with stand) | 337.5 mm |
| Depth (with stand) | 44.5 mm |
| Height (with stand) | 265.5 mm |
| Weight (with stand) | 2.7 kg |
| Width (without stand) | 337.5 mm |
| Depth (without stand) | 44.5 mm |
| Height (without stand) | 265.5 mm |
| Weight (without stand) | 2.7 kg |
| Power cable length | 1.8 m |
| Water and dust resistance (IP rating) | IP65 |
| Weight | 2.7 kg |
| Height | 265.5 mm |
| Width | 337.5 mm |
| Depth | 44.5 mm |
Software & compatibility2 details
| Compatible operating systems | All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
|---|---|
| Compliance certificates | CE, cULus, EAC, REACH, RoHS, WEEE |
Further product details19 details
| HD type | XGA |
|---|---|
| Native aspect ratio | 4:3 |
| Touch technology | Multi-touch |
| Pixel pitch | 0.297 x 0.297 mm |
| Viewable size, horizontal | 30.4 cm |
| Viewable size, vertical | 22.8 cm |
| Surface hardness | 7H |
| NVIDIA G-SYNC | No |
| AMD FreeSync | No |
| Palm rejection | Yes |
| HDCP | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Number of OSD languages | 7 |
| Quick start guide | Yes |
| Sustainability certificates | ErP |
| Positional accuracy | 2 mm |
| Touch method | stylus, finger, glove (latex) |
| Mean time between failures (MTBF) | 50000 h |
Packaging & supplied accessories11 details
| Package width | 435 mm |
|---|---|
| Package depth | 165 mm |
| Package height | 335 mm |
| Package weight | 4 kg |
| Cables included | AC, USB, HDMI, DisplayPort |
| Packaging content | AC adapter |
| Products per pallet | 78 pc(s) |
| Pallet net width | 91 cm |
| Pallet net length | 198.7 cm |
| Pallet net height | 114 cm |
| Harmonized System (HS) code | 85285210 |
Specifications describe the supplied product data, not measured review results. Battery life, range and performance figures are source claims and can vary with use.
