iiyama TF1633MSC-B1 reviews
Product specifications and review coverage for this exact model.
Image supplied through Icecat
Product overview
iiyama TF1633MSC-B1 is listed in the computer monitors category. The recorded specifications include display diagonal: 39.6 cm (15.6"); display resolution: 1920 x 1080 pixels; panel type: IPS; maximum refresh rate: 60 Hz. This entry covers manufacturer code TF1633MSC-B1. Specifications relate to this exact source record; other editions or packages may differ.
Automatically assembled from the source specifications. This is a factual summary, not a hands-on review.
Expert reviews
No scored critic reviews have been imported for this exact product yet. It remains unrated.
The COR Score gives each publisher one rating. Scores are converted to the same five-point scale.
Specifications
Manufacturer code: TF1633MSC-B1. Icecat product 115171057 · Checked 16 Sep 2026. The source lists this code for Great Britain. No specifications are transferred from other editions.
Key specifications
The main features to compare for this exact model. Missing details are not assumed.
| Screen size | 39.6 cm (15.6") |
|---|---|
| Screen resolution | 1920 x 1080 pixels |
| Panel type | IPS |
| Maximum refresh rate | 60 Hz |
| Response time | 5 ms |
| Display brightness (typical) | 450 cd/m² |
| DisplayPort connections | 1 |
More product specifications
Open a section for the details that matter to you.
Audio & listening3 details
| Number of speakers | 2 |
|---|---|
| Rated audio power (RMS) | 4 W |
| Built-in speakers | Yes |
Display14 details
| Touchscreen | Yes |
|---|---|
| Touchscreen technology | Projected capacitive system |
| Display brightness | 385 cd/m² |
| Screen shape | Flat |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.7 million colours |
| Display diagonal (metric) | 39.5 cm |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Traditional Chinese, Czech, German, English, Spanish, French, Italian, Japanese, Dutch, Polish, Portuguese, Russian |
| Brightness | 385 cd/m² |
| Active display area (W x H) | 344.2 x 193.6 mm |
| Native refresh rate | 60 Hz |
Camera, image & video1 detail
| Built-in camera | No |
|---|
Printing, scanning & paper1 detail
| Horizontal scan range | 30 - 68 kHz |
|---|
Connections & wireless7 details
| Number of simultaneous touchpoints | 10 |
|---|---|
| Built-in USB hub | Yes |
| USB hub version | 2.0 |
| Number of downstream ports | 2 |
| HDMI | Yes |
| Panel mounting interface | 100 x 100 mm |
| USB ports quantity | 2 |
Power & battery10 details
| Energy efficiency class (SDR) | C |
|---|---|
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 7.7 kWh |
| Power consumption (typical) | 12 W |
| Power consumption (standby) | 0.4 W |
| Power consumption (off) | 0.3 W |
| AC adapter output voltage | 12 V |
| Power supply type | External |
| Energy efficiency scale | A to G |
| AC adapter included | Yes |
Controls & features2 details
| User controls | Luminance (contrast, brightness, i-Style color, adv. contrast, overdrive), image setup (aspect ratio), color temp., OSD setup (H. position, V. position, timeout, language, touch wake up), extra (input select, DDC/CI, reset, opening logo, LED, volume, information) |
|---|---|
| Control panel | Power, Menu, Volume +, Volume -, Input |
Design & dimensions17 details
| Product colour | Black |
|---|---|
| Front bezel colour | Black |
| VESA mounting | Yes |
| Height adjustment | No |
| Width (with stand) | 389 mm |
| Depth (with stand) | 45.5 mm |
| Height (with stand) | 246.5 mm |
| Weight (with stand) | 2 kg |
| Width (without stand) | 389 mm |
| Depth (without stand) | 45.5 mm |
| Height (without stand) | 246.5 mm |
| Weight (without stand) | 2 kg |
| Water and dust resistance (IP rating) | IP54 |
| Weight | 2 kg |
| Height | 246.5 mm |
| Width | 389 mm |
| Depth | 45.5 mm |
Software & compatibility2 details
| Compliance certificates | CE, EAC, REACH, RoHS, TÜV mark, UKCA, WEEE |
|---|---|
| Certification | CE, TÜV-Bauart, EAC, RoHS, ErP, WEEE, REACH, UKCA |
Further product details22 details
| HD type | Full HD |
|---|---|
| Native aspect ratio | 16:9 |
| Response time measurement type | GTG (Gray to Gray) |
| Pixel pitch | 0.179 x 0.179 mm |
| Viewable size, horizontal | 34.4 cm |
| Viewable size, vertical | 19.4 cm |
| DDC/CI | Yes |
| AMD FreeSync | No |
| Low Blue Light technology | Yes |
| Palm rejection | Yes |
| Market positioning | Home |
| HDCP | Yes |
| Cable management | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Tilt adjustment | Yes |
| Tilt angle range | 90 - 5° |
| Number of OSD languages | 12 |
| Power adapter included | Yes |
| Quick start guide | Yes |
| Sustainability certificates | ErP |
| Touch method | stylus, finger, glove (latex) |
Packaging & supplied accessories7 details
| Package width | 475 mm |
|---|---|
| Package depth | 169 mm |
| Package height | 343 mm |
| Package weight | 3.9 kg |
| Package type | Box |
| Cables included | AC, USB, HDMI |
| Packaging content | AC adapter |
Specifications describe the supplied product data, not measured review results. Battery life, range and performance figures are source claims and can vary with use.
