Lenovo M93p Tiny reviews
Product specifications and review coverage for this exact model.
Image supplied through Icecat
Product overview
Lenovo 10ABS00Q00 is listed in the pcs/workstations category. The recorded specifications include processor family: Intel® Core™ i5; internal memory: 4 GB; total storage capacity: 500 GB; operating system installed: Windows 7 Professional. This entry covers manufacturer code 10ABS00Q00. Specifications relate to this exact source record; other editions or packages may differ.
Automatically assembled from the source specifications. This is a factual summary, not a hands-on review.
Expert reviews
No scored critic reviews have been imported for this exact product yet. It remains unrated.
The COR Score gives each publisher one rating. Scores are converted to the same five-point scale.
Specifications
Manufacturer code: 10ABS00Q00. Icecat product 21999608 · Checked 15 Sep 2026. The source lists this code for Great Britain. No specifications are transferred from other editions.
Key specifications
The main features to compare for this exact model. Missing details are not assumed.
| Processor family | Intel® Core™ i5 |
|---|---|
| Processor model | i5-4570T |
| Memory (RAM) | 4 GB |
| Total storage capacity | 500 GB |
| Storage media | HDD |
| Operating system installed | Windows 7 Professional |
| Discrete graphics card model | Not available |
| Chassis type | Mini PC |
| Ethernet LAN | Yes |
More product specifications
Open a section for the details that matter to you.
Audio & listening2 details
| Headphone outputs | 1 |
|---|---|
| Microphone in | Yes |
Display3 details
| Number of displays supported (on-board graphics) | 3 |
|---|---|
| Intel Dual Display Capable Technology | Yes |
| Display included | No |
Processor, memory & storage48 details
| Processor manufacturer | Intel |
|---|---|
| Processor generation | 4th gen Intel® Core™ i5 |
| Processor cores | 2 |
| Processor threads | 4 |
| Processor boost frequency | 3.6 GHz |
| Processor frequency | 2.9 GHz |
| Processor cache | 4 MB |
| Processor cache type | Smart Cache |
| Processor lithography | 22 nm |
| Processor operating modes | 64-bit |
| Processor series | Intel Core i5-4500 Desktop Series |
| Processor codename | Haswell |
| Number of processors installed | 1 |
| Processor socket | LGA 1150 (Socket H3) |
| Maximum internal memory supported by processor | 32 GB |
| Memory types supported by processor | DDR3-SDRAM |
| Memory clock speeds supported by processor | 1333,1600 MHz |
| Memory bandwidth supported by processor (max) | 25.6 GB/s |
| ECC supported by processor | No |
| Maximum internal memory | 16 GB |
| Internal memory type | DDR3-SDRAM |
| Memory slots | 2x SO-DIMM |
| Memory clock speed | 1600 MHz |
| Number of storage drives installed | 1 |
| Number of storage drives supported | 1 |
| HDD capacity | 500 GB |
| HDD size | 2.5" |
| Card reader integrated | No |
| On-board graphics card | Yes |
| On-board graphics card family | Intel® HD Graphics |
| On-board graphics card model | Intel® HD Graphics 4600 |
| On-board graphics card base frequency | 200 MHz |
| On-board graphics card dynamic frequency (max) | 1150 MHz |
| Maximum on-board graphics card memory | 1.7 GB |
| On-board graphics card DirectX version | 11.1 |
| On-board graphics card ID | 0x412 |
| Motherboard chipset | Intel® Q87 |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel® Smart Cache | Yes |
| Processor package size | 37.5 x 37.5 mm |
| Processor code | SR1CA |
| Graphics & IMC lithography | 22 nm |
| Intel Stable Image Platform Program (SIPP) version | 1.00 |
| Intel Rapid Storage Technology | No |
| Processor ARK ID | 75045 |
| Conflict-Free processor | Yes |
| Storage temperature (T-T) | -40 - 60 °C |
| Storage relative humidity (H-H) | 20 - 90% |
Camera, image & video4 details
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
|---|---|
| Intel Clear Video Technology | No |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel® Quick Sync Video Technology | Yes |
Connections & wireless8 details
| HDD interface | SATA |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 5 |
| DisplayPort connections | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| VGA (D-Sub) ports quantity | 1 |
| DVI port | No |
| Intel® Wireless Display (Intel® WiDi) | Yes |
Power & battery2 details
| Power supply | 65 W |
|---|---|
| AC adapter included | Yes |
Controls & features3 details
| Intel® Smart Response Technology | No |
|---|---|
| Intel Smart Connect Technology | No |
| Operating temperature (T-T) | 10 - 35 °C |
Design & dimensions10 details
| Thermal Design Power (TDP) | 35 W |
|---|---|
| Product type | Mini PC |
| Placement supported | Horizontal/Vertical |
| Product colour | Black |
| Intel Identity Protection Technology version | 1.00 |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Width | 34.5 mm |
| Depth | 182 mm |
| Height | 179 mm |
| Weight | 1.3 kg |
Software & compatibility7 details
| Operating system architecture | 64-bit |
|---|---|
| Operating system language | German |
| Trial software | Norton Internet Security 2013, Microsoft Office 2013 |
| Bundled software | Adobe Acrobat Reader Cyberlink PowerDVD Cyberlink Create Desktop Power Manager Evernote Intel Small Business Advantage Lenovo Message Center Plus Nitro PDF RapidBoot HDD Accelerator Skype ThinkVantage System Update ThinkVantage Rescue and Recovery ThinkVantage Password Manager |
| Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
| Compliance certificates | RoHS |
| Certification | CC DoC, VCCI, BSMI, EU/EFTA CE Mark & DoC, UL/CUL, TUV-GS, IEC60950-1 CB, ICCP(SASO), CCC Mark, SAR, S-mark, PSB, SABS, GOST, NOM, GOST-K, KVALITET, UKrCEPRO, PEP, WEEE, J-Moss |
Further product details57 details
| System bus rate | 5 GT/s |
|---|---|
| Bus type | DMI |
| FSB Parity | No |
| Tcase | 66.35 °C |
| PCI Express slots version | 3.0 |
| Maximum number of PCI Express lanes | 16 |
| PCI Express configurations | 1x16, 2x8, 1x8+2x4 |
| Stepping | C0 |
| Non-ECC | Yes |
| Memory channels | Dual-channel |
| Number of HDDs installed | 1 |
| Cabling technology | 10/100/1000Base-T(X) |
| Mini PCI Express slots | 1 |
| Volume | 1 L |
| Water cooling system | No |
| Number of 2.5" bays | 1 |
| Cable lock slot | Yes |
| Intel® Small Business Advantage (Intel® SBA) | No |
| Intel 64 | Yes |
| Intel® Virtualization Technology (Intel® VT) | VT-d, VT-x |
| Enhanced Intel SpeedStep Technology | Yes |
| Embedded options available | No |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Insider™ | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel TSX-NI | No |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Secure Key | Yes |
| Intel® OS Guard | Yes |
| Intel Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| Intel FDI Technology | Yes |
| Intel Flex Memory Access | No |
| Intel Fast Memory Access | No |
| Intel Enhanced Halt State | Yes |
| Intel Demand Based Switching | No |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Thermal solution specification | PCG 2013A |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Secure Key Technology version | 1.00 |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Small Business Advantage (SBA) version | 1.00 |
| Intel TSX-NI version | 0.00 |
| Intel® Rapid Start Technology | No |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® My WiFi Technology (Intel® MWT) | Yes |
| Intel® Anti-Theft Technology (Intel® AT) | Yes |
| Operating relative humidity (H-H) | 20 - 80% |
| Non-operating altitude | -15.2 - 3048 m |
| Mouse included | No |
| Keyboard included | No |
| Sustainability certificates | EPEAT Gold, ENERGY STAR |
| Intel segment tagging | Enterprise, Professional |
Packaging & supplied accessories1 detail
| Manual | Yes |
|---|
Specifications describe the supplied product data, not measured review results. Battery life, range and performance figures are source claims and can vary with use.
