Image supplied through Icecat
Product overview
Lenovo 20Y300B2UK is listed in the laptops category. The recorded specifications include display diagonal: 40.6 cm (16"); processor family: Intel® Core™ i7; internal memory: 16 GB; total storage capacity: 512 GB. This entry covers manufacturer code 20Y300B2UK. Specifications relate to this exact source record; other editions or packages may differ.
Automatically assembled from the source specifications. This is a factual summary, not a hands-on review.
Expert reviews
No scored critic reviews have been imported for this exact product yet. It remains unrated.
The COR Score gives each publisher one rating. Scores are converted to the same five-point scale.
Specifications
Manufacturer code: 20Y300B2UK. Icecat product 112609254 · Checked 16 Sep 2026. The source lists this code for Great Britain. No specifications are transferred from other editions.
Key specifications
The main features to compare for this exact model. Missing details are not assumed.
Lenovo ThinkPad P1 Gen 4 — key specifications
Screen size
40.6 cm (16")
Screen resolution
2560 x 1600 pixels
Processor family
Intel® Core™ i7
Processor model
i7-11800H
Memory (RAM)
16 GB
Total storage capacity
512 GB
Storage media
SSD
Operating system installed
Windows 11 Pro
Discrete graphics card model
NVIDIA RTX A2000
Weight
1.81 kg
More product specifications
Open a section for the details that matter to you.
Audio & listening6 details
Lenovo ThinkPad P1 Gen 4 — Audio & listening
Discrete GPU manufacturer
NVIDIA
Audio chip
Realtek ALC3306
Audio system
Dolby Atmos
Number of built-in speakers
2
Built-in microphone
Yes
Number of microphones
2
Display6 details
Lenovo ThinkPad P1 Gen 4 — Display
Touchscreen
No
Panel type
IPS
Anti-glare screen
Yes
Display brightness
400 cd/m²
Colour gamut
100%
Contrast ratio (typical)
1200:1
Processor, memory & storage25 details
Lenovo ThinkPad P1 Gen 4 — Processor, memory & storage
Processor manufacturer
Intel
Processor generation
11th gen Intel® Core™ i7
Processor cores
8
Processor boost frequency
4.6 GHz
Processor frequency
2.3 GHz
Processor cache
24 MB
Processor cache type
Smart Cache
Internal memory type
DDR4-SDRAM
Memory clock speed
3200 MHz
Memory layout (slots x size)
1 x 16 GB
Memory slots
2x SO-DIMM
Maximum internal memory
64 GB
SSD capacity
512 GB
SSD form factor
M.2
Card reader integrated
Yes
Compatible memory cards
SD
Discrete graphics card memory
4 GB
Discrete graphics memory type
GDDR6
On-board graphics card
Yes
Discrete graphics card
Yes
On-board graphics card family
Intel® UHD Graphics
On-board graphics card model
Intel® UHD Graphics
Motherboard chipset
Intel WM590
Storage temperature (T-T)
5 - 43 °C
Storage relative humidity (H-H)
5 - 95%
Camera, image & video5 details
Lenovo ThinkPad P1 Gen 4 — Camera, image & video
Front camera
Yes
Front camera resolution
1920 x 1080 pixels
Front camera HD type
Full HD
Infrared (IR) camera
Yes
Privacy camera
Yes
Printing, scanning & paper1 detail
Lenovo ThinkPad P1 Gen 4 — Printing, scanning & paper
Fingerprint reader
Yes
Connections & wireless13 details
Lenovo ThinkPad P1 Gen 4 — Connections & wireless
SSD interface
PCI Express 4.0
Top Wi-Fi standard
Wi-Fi 6E (802.11ax)
Wi-Fi standards
Wi-Fi 6E (802.11ax)
Mobile network connection
No
Bluetooth
Yes
Bluetooth version
5.1
NFC
No
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
Thunderbolt 4 ports quantity
2
Combo headphone/mic port
Yes
USB Type-C DisplayPort Alternate Mode
Yes
USB Sleep-and-Charge
Yes
USB Sleep-and-Charge ports
1
Power & battery8 details
Lenovo ThinkPad P1 Gen 4 — Power & battery
Battery technology
Lithium Polymer (LiPo)
Battery capacity
90 Wh
Maximum stated battery life
10.9 h
Fast charging
Yes
AC adapter power
170 W
AC adapter frequency
50/60 Hz
AC adapter input voltage
100 - 240 V
USB Power Delivery (USB PD)
Yes
Controls & features3 details
Lenovo ThinkPad P1 Gen 4 — Controls & features
WLAN controller model
Intel Wi-Fi 6E AX210
WLAN controller manufacturer
Intel
Operating temperature (T-T)
5 - 35 °C
Design & dimensions12 details
Lenovo ThinkPad P1 Gen 4 — Design & dimensions
Colour name
Black
Product type
Mobile workstation
Product colour
Black
Form factor
Clamshell
Housing material
Aluminium
RGB colour space
sRGB
Memory form factor
SO-DIMM
Password protection
Yes
Password protection type
Power on, SSD, Supervisor
Width
359.5 mm
Depth
253.8 mm
Height
17.7 mm
Software & compatibility4 details
Lenovo ThinkPad P1 Gen 4 — Software & compatibility
Operating system architecture
64-bit
Operating system language
English
Compliance certificates
RoHS
Certification
EPEAT Gold ENERGY STAR 8.0 RoHS compliant MIL-STD-810H
Further product details26 details
Lenovo ThinkPad P1 Gen 4 — Further product details
HD type
WQXGA
LED backlight
Yes
Native aspect ratio
16:10
Non-ECC
Yes
Total SSDs capacity
512 GB
Number of SSDs installed
1
NVMe
Yes
Optical drive type
No
On-board GPU manufacturer
Intel
Privacy type
Privacy shutter
Antenna type
2x2
WWAN
Not installed
Intel® Thunderbolt 4
Yes
Pointing device
ThinkPad UltraNav
Numeric keypad
No
Keyboard backlit
Yes
Spill-resistant keyboard
Yes
Keyboard language
UK English
Cable lock slot
Yes
Cable lock slot type
Kensington
Windows Hello
Yes
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
Operating relative humidity (H-H)
8 - 95%
Maximum shipping altitude
3048 m
Sustainability certificates
ENERGY STAR, EPEAT Gold
Packaging & supplied accessories1 detail
Lenovo ThinkPad P1 Gen 4 — Packaging & supplied accessories
Packaging content
Lenovo USB-C to Ethernet Adapter (1Gbps)
Specifications describe the supplied product data, not measured review results. Battery life, range and performance figures are source claims and can vary with use.
