Product overview
NEC 60003488 is listed in the computer monitors category. The recorded specifications include display diagonal: 75.7 cm (29.8"); display resolution: 2560 x 1600 pixels; panel type: AH-IPS. This entry covers manufacturer code 60003488. Specifications relate to this exact source record; other editions or packages may differ.
Automatically assembled from the source specifications. This is a factual summary, not a hands-on review.
Expert reviews
No scored critic reviews have been imported for this exact product yet. It remains unrated.
The COR Score gives each publisher one rating. Scores are converted to the same five-point scale.
Specifications
Manufacturer code: 60003488. Icecat product 20114005 · Checked 21 Sep 2026. The source lists this code for Great Britain. No specifications are transferred from other editions.
Key specifications
The main features to compare for this exact model. Missing details are not assumed.
| Screen size | 75.7 cm (29.8") |
|---|---|
| Screen resolution | 2560 x 1600 pixels |
| Panel type | AH-IPS |
| Response time | 6 ms |
| Display brightness (typical) | 340 cd/m² |
| HDMI ports | 1 |
| DisplayPort connections | 1 |
More product specifications
Open a section for the details that matter to you.
Display8 details
| Display technology | LED |
|---|---|
| Touchscreen | No |
| Screen shape | Flat |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Colour gamut standard | sRGB |
| On Screen Display (OSD) | Yes |
Processor, memory & storage3 details
| Supported graphics resolutions | 640 x 480 (VGA), 720 x 400, 720 x 480, 720 x 576, 800 x 600 (SVGA), 832 x 624, 1024 x 768 (XGA), 1152 x 864 (XGA+), 1152 x 870, 1200 x 1920, 1280 x 720 (HD 720), 1280 x 960, 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 2560 x 1600 (WQXGA) |
|---|---|
| Storage temperature (T-T) | -10 - 60 °C |
| Storage relative humidity (H-H) | 10 - 85% |
Printing, scanning & paper2 details
| Horizontal scan range | 31.5 - 98.7 kHz |
|---|---|
| Vertical scan range | 50 - 85 Hz |
Connections & wireless10 details
| Built-in USB hub | Yes |
|---|---|
| Number of upstream ports | 2 |
| USB Type-A downstream ports quantity | 3 |
| DVI port | Yes |
| DVI-D ports quantity | 1 |
| Mini DisplayPorts quantity | 1 |
| Wi-Fi | No |
| Bluetooth | No |
| Ethernet LAN | No |
| Panel mounting interface | 100 x 100,200 x 100 mm |
Power & battery8 details
| Power consumption (typical) | 63 W |
|---|---|
| Power consumption (max) | 87 W |
| Power consumption (PowerSave) | 1.4 W |
| AC input voltage | 100 - 240 V |
| Annual energy consumption | 92 kWh |
| Power consumption (economy mode) | 47 W |
| Energy efficiency class (legacy scale) | C |
| Supplied AC adapter type | AC |
Controls & features2 details
| Operating temperature (T-T) | 5 - 35 °C |
|---|---|
| Light sensor | Yes |
Design & dimensions15 details
| Product colour | Black |
|---|---|
| VESA mounting | Yes |
| Height adjustment | Yes |
| Adjustable height (max) | 15 cm |
| Width (with stand) | 688 mm |
| Depth (with stand) | 301.6 mm |
| Height (with stand) | 466.6 mm |
| Weight (with stand) | 17 kg |
| Width (without stand) | 688 mm |
| Depth (without stand) | 82 mm |
| Height (without stand) | 446.8 mm |
| Weight (without stand) | 10.7 kg |
| Bezel width (side) | 2.24 cm |
| Bezel width (top) | 2.2 cm |
| Bezel width (bottom) | 2.2 cm |
Software & compatibility2 details
| Windows operating systems supported | Windows 8 |
|---|---|
| Certification | C-tick; CCC; CE; ErP; FCC Class B; ISO 9241-307 (pixel failure class I); MPR II/ MPR III; PCBC/B-mark; PCT/Gost; PSB; RoHS; TÜV Ergonomics; TÜV GS; UL/C-UL, CSA |
Further product details27 details
| HD type | Quad HD |
|---|---|
| Native aspect ratio | 16:10 |
| Backlight type | RGB LED |
| Aspect ratio | 16:10 |
| DDC/CI | Yes |
| 3D | No |
| HDCP | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Pivot | Yes |
| Pivot angle | 0 - 90° |
| Swivelling | Yes |
| Swivel angle range | -45 - 45° |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 30° |
| Picture-in-Picture | Yes |
| Plug and Play | Yes |
| LED indicators | Power |
| Operating relative humidity (H-H) | 30 - 80% |
| Operating altitude | 0 - 5000 m |
| Non-operating altitude | 0 - 12192 m |
| User Guide on CD-ROM | Yes |
| Quick start guide | Yes |
| On/off switch | Yes |
| ECO mode | Yes |
| Power management | Yes |
| Thin client installed | No |
Packaging & supplied accessories1 detail
| Cables included | DVI, Mini DisplayPort |
|---|
Specifications describe the supplied product data, not measured review results. Battery life, range and performance figures are source claims and can vary with use.
