iiyama TF2234MC-B7AGB reviews
Product specifications and review coverage for this exact model.
Image supplied through Icecat
Product overview
iiyama TF2234MC-B7AGB is listed in the computer monitors category. The recorded specifications include display diagonal: 54.6 cm (21.5"); display resolution: 1920 x 1080 pixels; panel type: IPS. This entry covers manufacturer code TF2234MC-B7AGB. Specifications relate to this exact source record; other editions or packages may differ.
Automatically assembled from the source specifications. This is a factual summary, not a hands-on review.
Expert reviews
No scored critic reviews have been imported for this exact product yet. It remains unrated.
The COR Score gives each publisher one rating. Scores are converted to the same five-point scale.
Specifications
Manufacturer code: TF2234MC-B7AGB. Icecat product 91028380 · Checked 14 Sep 2026. The source lists this code for Great Britain. No specifications are transferred from other editions.
Key specifications
The main features to compare for this exact model. Missing details are not assumed.
| Screen size | 54.6 cm (21.5") |
|---|---|
| Screen resolution | 1920 x 1080 pixels |
| Panel type | IPS |
| Response time | 8 ms |
| Display brightness (typical) | 350 cd/m² |
| HDMI ports | 1 |
| DisplayPort connections | 1 |
More product specifications
Open a section for the details that matter to you.
Audio & listening1 detail
| Built-in microphone | No |
|---|
Display17 details
| Display technology | LED |
|---|---|
| Touchscreen | Yes |
| Touchscreen type | Multi-user |
| Touchscreen technology | Projected capacitive system |
| Display brightness | 300 cd/m² |
| Anti-glare screen | Yes |
| Screen shape | Flat |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.7 million colours |
| Display diagonal (metric) | 54.6 cm |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | German, English, Spanish, French, Italian, Japanese, Dutch, Polish, Russian |
| Display viewable area (HxV) | 476 x 267.7 mm |
| Brightness | 300 cd/m² |
| Active display area (W x H) | 476 x 267.7 mm |
Camera, image & video1 detail
| Built-in camera | No |
|---|
Printing, scanning & paper1 detail
| Horizontal scan range | 30 - 84 kHz |
|---|
Connections & wireless5 details
| Number of simultaneous touchpoints | 10 |
|---|---|
| USB Touch port | Yes |
| VGA (D-Sub) ports quantity | 1 |
| HDMI | Yes |
| Panel mounting interface | 100 x 100 mm |
Power & battery9 details
| Energy efficiency class (SDR) | F |
|---|---|
| Energy consumption (SDR) per 1000 hours | 19 kWh |
| Power consumption (typical) | 18 W |
| Power consumption (standby) | 1.5 W |
| Power consumption (off) | 0.3 W |
| AC adapter output voltage | 12 V |
| Power supply type | External |
| Energy efficiency scale | A to G |
| AC adapter included | Yes |
Controls & features2 details
| User controls | picture (contrast, brightness, H.position, V.position, phase, clock, auto adjust), advanced (color temp., sharpness), OSD (time out, position, H-position, V-position, Touch switch), option (reset, language, source select, display mode, factory) |
|---|---|
| Control panel | Menu, Scroll up/ Brightness, Scroll down/ Contrast, Select, Power |
Design & dimensions18 details
| Product colour | Black |
|---|---|
| Front bezel colour | Black |
| VESA mounting | Yes |
| Wall mountable | Yes |
| Width (with stand) | 517.5 mm |
| Depth (with stand) | 46 mm |
| Height (with stand) | 313.5 mm |
| Weight (with stand) | 4.4 kg |
| Width (without stand) | 517.5 mm |
| Depth (without stand) | 46 mm |
| Height (without stand) | 313.5 mm |
| Weight (without stand) | 4.4 kg |
| Water and dust resistance (IP rating) | IP65 |
| Placement supported | Horizontal/Vertical |
| Weight | 4.4 kg |
| Height | 313.5 mm |
| Width | 517.5 mm |
| Depth | 46 mm |
Software & compatibility2 details
| Compatible operating systems | All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
|---|---|
| Compliance certificates | CE, cULus, EAC, REACH, RoHS, WEEE |
Further product details17 details
| HD type | Full HD |
|---|---|
| Native aspect ratio | 16:9 |
| Touch technology | Multi-touch |
| Response time measurement type | GTG (Gray to Gray) |
| Pixel pitch | 0.247 x 0.247 mm |
| Viewable size, horizontal | 47.6 cm |
| Viewable size, vertical | 26.8 cm |
| Surface hardness | 6H |
| NVIDIA G-SYNC | No |
| AMD FreeSync | No |
| Palm rejection | Yes |
| Glass thickness | 1.5 mm |
| HDCP | Yes |
| Number of OSD languages | 9 |
| Quick start guide | Yes |
| Sustainability certificates | ErP |
| Touch method | stylus, finger, glove (latex) |
Packaging & supplied accessories11 details
| Package width | 610 mm |
|---|---|
| Package depth | 160 mm |
| Package height | 405 mm |
| Package weight | 6.8 kg |
| Cables included | AC, USB, HDMI, DisplayPort |
| Packaging content | AC adapter |
| Products per pallet | 48 pc(s) |
| Pallet net width | 109 cm |
| Pallet net length | 192.7 cm |
| Pallet net height | 109 cm |
| Harmonized System (HS) code | 85285210 |
Specifications describe the supplied product data, not measured review results. Battery life, range and performance figures are source claims and can vary with use.
