Viewsonic TD2423 reviews
Product specifications and review coverage for this exact model.
Image supplied through Icecat
Product overview
Viewsonic TD2423 is listed in the computer monitors category. The recorded specifications include display diagonal: 59.9 cm (23.6"); display resolution: 1920 x 1080 pixels; panel type: VA; maximum refresh rate: 60 Hz. This entry covers manufacturer code TD2423. Specifications relate to this exact source record; other editions or packages may differ.
Automatically assembled from the source specifications. This is a factual summary, not a hands-on review.
Expert reviews
No scored critic reviews have been imported for this exact product yet. It remains unrated.
The COR Score gives each publisher one rating. Scores are converted to the same five-point scale.
Specifications
Manufacturer code: TD2423. Icecat product 89444556 · Checked 16 Sep 2026. The source lists this code for Great Britain. No specifications are transferred from other editions.
Key specifications
The main features to compare for this exact model. Missing details are not assumed.
| Screen size | 59.9 cm (23.6") |
|---|---|
| Screen resolution | 1920 x 1080 pixels |
| Panel type | VA |
| Maximum refresh rate | 60 Hz |
| Response time | 7 ms |
| HDMI ports | 1 |
More product specifications
Open a section for the details that matter to you.
Audio & listening8 details
| Digital horizontal frequency | 24 - 82 kHz |
|---|---|
| Digital vertical frequency | 50 - 75 Hz |
| Number of speakers | 2 |
| Rated audio power (RMS) | 4 W |
| Built-in speakers | Yes |
| Built-in microphone | No |
| Audio input | 1 |
| Audio output | 1 |
Display13 details
| Display technology | LED |
|---|---|
| Touchscreen | Yes |
| Touchscreen type | Multi-user |
| Touchscreen technology | Infrared |
| Display brightness | 250 cd/m² |
| Screen shape | Flat |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.78 million colours |
| Display diagonal (metric) | 59.94 cm |
| Display viewable area (HxV) | 521 x 293 mm |
| Native refresh rate | 60 Hz |
Camera, image & video1 detail
| Built-in camera | No |
|---|
Connections & wireless11 details
| Number of simultaneous touchpoints | 10 |
|---|---|
| Built-in USB hub | Yes |
| USB upstream port type | USB Type-B |
| Number of upstream ports | 1 |
| USB Type-A downstream ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| DVI port | Yes |
| DVI-D ports quantity | 1 |
| HDMI | Yes |
| HDMI version | 1.4 |
| Panel mounting interface | 100 x 100 mm |
Power & battery10 details
| Energy efficiency class (SDR) | D |
|---|---|
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 14 kWh |
| Power consumption (typical) | 15.5 W |
| Power consumption (standby) | 0.2 W |
| Power consumption (max) | 16.5 W |
| Power consumption (off) | 0.1 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| Power supply type | AC |
Controls & features1 detail
| Operating temperature (T-T) | 0 - 40 °C |
|---|
Design & dimensions12 details
| Product colour | Black |
|---|---|
| VESA mounting | Yes |
| Wall mountable | Yes |
| Width (with stand) | 571 mm |
| Depth (with stand) | 101 mm |
| Height (with stand) | 348 mm |
| Weight (with stand) | 5.2 kg |
| Width (without stand) | 571 mm |
| Depth (without stand) | 61 mm |
| Height (without stand) | 348 mm |
| Weight (without stand) | 4.7 kg |
| Weight | 5.2 kg |
Software & compatibility2 details
| Compliance certificates | CE, REACH, RoHS |
|---|---|
| Certification | cTUVus, FCC-B, ICES003, Energy Star 8.0, EPEAT Silver, CEC, MX-CoC, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, BSMI, RCM, GEMS, PSE, CCC, China RoHS, China Energy Label, CECP |
Further product details14 details
| HD type | Full HD |
|---|---|
| Native aspect ratio | 16:9 |
| Touch technology | Multi-touch |
| Pixel pitch | 0.271 x 0.271 mm |
| NVIDIA G-SYNC | No |
| AMD FreeSync | No |
| Glass thickness | 1.85 mm |
| HDCP | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Tilt adjustment | Yes |
| Tilt angle range | 22 - 38° |
| Operating relative humidity (H-H) | 20 - 90% |
| Sustainability certificates | EPEAT Silver |
Packaging & supplied accessories10 details
| Package width | 645 mm |
|---|---|
| Package depth | 166 mm |
| Package height | 422 mm |
| Package weight | 7 kg |
| Cables included | AC, Audio (3.5mm), HDMI, USB Type-A to USB Type-B |
| Products per master (outer) case | 1 pc(s) |
| Pallet gross width | 120 cm |
| Pallet gross length | 100 cm |
| Pallet gross height | 2.24 m |
| Harmonized System (HS) code | 8528521000 |
Specifications describe the supplied product data, not measured review results. Battery life, range and performance figures are source claims and can vary with use.
